Raspberry Pi - DS18B20 1-Wire Temp Sensor

Product Code:pi-18b20-v1
Availability:10
Weight:0.30kg
Price:£3.15

This  DS18B20 1-WIRE Digital Thermometer with 9 to 12 bit programmable resolution.

  • Unique 1-Wire interface only requires ONE data pin for communication
  • Each device has a unique 64-bit serial number stored in an on-board ROM
  • Can be powered from the data line with a power supply range of 3.0V to 5.5V in Parasite mode
  • Measures temperatures from -55°C to +125°C
  • ±0.5°C accuracy from -10°C to +85°C
  • Thermometer resolution is user-selectable from 9 to 12 bits
  • Converts temperature to 12-bit digital word in 750ms (max)
  • Demo Python program
  • Minimum Requirements – a Raspberry Pi with Raspbian (wheezy) installed ,
