The μPD720200 is the Universal Serial Bus 3.0 host controller, based upon Universal Serial Bus 3.0 Specification, and Intel’s eXtensible Host Controller Interface (xHCI).
The μPD720200 has PCI Express® bus interface, and it is applicable for PCI Express solution for host PC system. The μPD720200 works up to 5 Gbps for data transfer when connecting to USB 3.0 compliant peripherals, while maintaining compatibility with existing USB peripheral devices.

Lastest Firmware  V 3.0.2.8   or  4.0.1.5

 Driver 1.0.18 & 1.0.19 & 2.1.28.0  2.1.28.1 can be download from  our web site.

FEATURES
• Based upon Universal Serial Bus 3.0 specification Revision 1.0, which is released by USB Implementers Forum, Inc
- Supports the following speed data rate as follows;
Low-speed (1.5 Mbps) / Full-speed (12 Mbps)

High-speed (480 Mbps) / Super-speed (5 Gbps)

- Supports 2 downstream ports for all speeds
- Supports all USB compliant data transfer type as follows; Control / Bulk / Interrupt / Isochronous transfer
• Based upon Intel’s eXtensible Host Controller Interface (xHCI) Specification revision 0.95
• Support USB legacy function
• Based upon PCI Express Base Specification 2.0
• Supports ExpressCardTM Standard Release 1.0
• Supports PCI Express Card Electromechanical Specification Revision 2.0
• Supports PCI Bus Power Management Interface Specification revision 1.2

• Single-lane (x1) PCI Express throughput rates up tp 5Gbps
• Each USB Port supplies maximum +5V/900ma power output to USB device.
